ISO9001 Approved Hybrid OEM CE, RoHS, UL, VDE Servo Stepping Motor

Basic Info

Product Description

Stepper MotorProduct Characteristics1.Precision step angle 1.8 ° / Step2.Can be customized according to customer requirements 0.9 °, 3 °, 3.6 °, 0.045 °,0.15 °, 0.18 ° step angle3.Step angle accuracy ± 0.09 ° (no load step)4.Resistance accuracy ± 10% according to customer requirements agreed smaller tolerance range5.Inductance Accuracy ± 20%6.Allowable temperature rise <80 ºC (rated current, two-phase power) can be customized according to customer requirements more low temperature or higher temperature7.Ambient temperature -20 ºC ~ +50 ºC (no freezing)8.Protection class IP43 IP54 or IP65 can be customized according to customer requirements9.Medium Environment No corrosive gas or dust. Not directly in contact with water, oil and other liquid requirements can be customized higher10.Environmental humidity below 85% below 40 ºC; 57% below below 50 ºC (no condensation)11.Insulation Class B (+ 130 ºC)12.Insulation withstand voltage 100MΩ Min. DC 500V13.Insulation resistance DC 500V Measured with a megger more than 100Ω14.Radial runout 0.02 Max. (450 gf)15.Axial Clearance 0.08 Max. (450gf)16.Axial displacement of 0.075mm.Max 10N load in the shaft end17.Radial displacement of 0.025mm.Max in the axial application of 5N load
